street light led driver

HVC 320W LED Driver

HVC-320W-56A,B,C, HVC-320W-428A,B,C
A-Adjustable potentiometer version
B-Three-in-one dimming version
C-12V auxiliary power version
Quantity:
Contact Now
Specifications

HVC 320W LED Driver Parameters

Input voltage: 100-277V (Wide Input Voltage)
Output voltage: 27-56V/214-428V
Rated power: 320W
Electrical performance parameters:  THD＜10%/PF＞0.95

Features of HVC 320W LED Driver
Class I type for insulation
Isolated flicker free LED driver
Constant current output ,with power limitation for control mode
Surge:  6/10KV
Metal material case, protection grade against water and dust: IP67
Protection: SCP/OVP/OTP
Global certifications: ENEC/CE/CCC/CB(C version is compliant with new ERP directive)
     Dimming function: Three-in-one dimming (resistance dimming, 1-10V dimming, PWM dimming) and 12V/0.25A auxiliary power
Warranty:  5 years

Applications of HVC 320W LED Driver
Street lighting, industrial lighting, stadium lighting, landscape lighting, plant lighting and other lighting lamps.


Model list

ModelRated PowerInput VoltageOutput VoltageOutpot CurrentProduct SizeTHD.(Typ)Pf.(Typ)
HVC-320W-56A320W100-277V27-56V4200-7650mA252*89*44mm<10%>0,95
HVC-320W-56B320W100-277V27-56V4200-7650mA252*89*44mm<10%>0,95
HVC-320W-56C320W100-277V27-56V4200-7650mA252*89*44mm<10%>0,95
HVC-320W-428A320W100-277V214-428V500-1050mA252*89*44mm<10%>0,95
HVC-320W-428B320W100-277V214-428V500-1050mA252*89*44mm<10%>0,95
HVC-320W-428C320W100-277V214-428V500-1050mA252*89*44mm<10%>0,95
