indoor led driver

HVE 50H LED driver

HVE-50H-38A,B, HVE-50H-56A,B,HVE-50H-72A,B
The LED driver is constant current output mode, designed for LED luminaires like street lighting, industrial lighting and other applications.The three-in-one dimming version supports three modes of dimming: 0-10V, PWM, and resistance. With isolated, low THD AND high PF features, this driver ensures high quality and safe operation. Choose the LED driver for reliable and efficient lighting solutions.

A-Adjustable potentiometer version
B- Three-in-one dimming version
Quantity:
Contact Now
Specifications
HVE 50H LED Power Supply Driver Parameters
Input voltage: 200-277V
Output voltage: 20-38V/36-72V
Rated power: 50W
THD＜10%/PF＞0.95

Features of HVE 50H LED Power Supply Driver
Class I type for insulation
Constant current output ,with power limitation for control mode
Efficiency: 89%（Typ.）
Surge protection: 4/6KV
Metal material case, IP67
Protection: UVP/SCP/OVP/OTP
Global certifications: CCC/CE/CB
Dimming function: 3-in-1 dimming (resistance dimming, 1-10V dimming, PWM dimming)
Working temperature: -40 ~ +55℃
Safety case temperature: -40 ~ 90℃
Storage temperature: -40~+80℃
Warranty: 5 years

Applications of HVE 50H LED Power Supply Driver
Our versatile lighting solutions cater to a wide spectrum of needs, encompassing indoor LED drivers for applications like street lighting, industrial lighting, stadium lighting, flood lighting, landscape lighting, and plant lighting.

Model list

ModelRated PowerInput VoltageOutput VoltageOutpot CurrentProduct SizeTHD.(Typ)Pf.(Typ)
HVE-50H-38A50W200-277V20-38V700-1600mA109*61*33mm<10%>0.95
HVE-50H-38B200-277V20-38V700-1600mA109*61*33mm<10%>0.95
HVE-50H-56A200-277V32-56V500-1200mA109*61*33mm<10%>0.95
HVE-50H-56B200-277V32-56V500-1200mA109*61*33mm<10%>0.95
HVE-50H-72A200-277V36-72V500-1050mA109*61*33mm<10%>0.95
HVE-50H-72B200-277V36-72V500-1050mA109*61*33mm<10%>0.95
