waterproof electronic led driver

HVE 100H LED driver

HVE-100H-38A,B, HVE-100H-56A,B, HVE-100H-143A,B
HVE is a high-quality power supply designed for LED lighting used in street lighting, industrial lighting and other lighting lamps. Its high efficiency ensures that energy is not wasted, making it an environmentally friendly choice.

A-Adjustable potentiometer version
B- Three-in-one dimming version
Quantity:
Contact Now
Specifications
HVE 100H Dimming LED Driver Parameters
Input voltage: 200-277V
Output voltage: 20-38V/32-56V/71-143V
Rated power: 100W
THD＜10%/PF＞0.95

Features of HVE 100H Dimming LED Driver
Class I type for insulation
Constant current output ,with power limitation for control mode
Efficiency: 90%（Typ.）
Surge protection: 6/10KV
Metal material case, IP67
Protection:  UVP/SCP/OVP/OTP
Global certifications: CCC/CE/CB
Dimming function: 3-in-1 dimming (1-10V dimming, resistance dimming, PWM dimming)
Output current is dimmed by external potentiometer (Only Type A)
Output current is dimmed by Isolated 3 in 1 dimmer（Only Type B）
Working temperature: -40 ~ 55℃
Safety case temperature: -40 ~ 90℃
Storage temperature: -40 ~ 80℃
Warranty:  5 years

Applications of HVE 100H Dimming LED Driver
Street lighting, industrial lighting, stadium lighting, floodlight lighting, landscape lighting, plant lighting

Model list

ModelRated PowerInput VoltageOutput VoltageOutpot CurrentProduct SizeTHD.(Typ)PF.(Typ)
HVE-100H-38A100W200-277V20-38V1900-3100mA156*61*33mm<10%>0.95
HVE-100H-38B200-277V20-38V1900-3100mA156*61*33mm<10%>0.95
HVE-100H-56A200-277V32-56V1300-2400mA156*61*33mm<10%>0.95
HVE-100H-56B200-277V32-56V1300-2400mA156*61*33mm<10%>0.95
HVE-100H-143A200-277V71-143V500-1050mA156*61*33mm<10%>0.95
HVE-100H-143B200-277V71-143V500-1050mA156*61*33mm<10%>0.95
