GSE 5W LED Driver
GSE-5W250-20,5W300-18
GSE series features a wide input voltage range and a constant current output, ensuring stable and reliable power supply to your LED lights. Built-in surge protection, output open circuit, short circuit protection, greatly improve the safety and reliability of the product.
Quantity:
GSE 5W LED Floodlight Driver Parameters
Rated input voltage: 100-265V
Output voltage: 9-20V/9-18V
Rated power: 5W
Features of GSE 5W LED Driver
Low PF isolated semi-aluminum waterproof LED driver
Isolation without LED driver, constant current mode output LED driver
Protections: Output OCP /SCP /OTP
IP grade: IP65
Surge protection grade: 1KV
Efficiency: ≥81%
Working temperature: -40 ~ 65℃ (Typ. 25℃ )
Maximum case temperature: 90℃
Storage temperature: -40 ~ 85℃ (Typ. 25℃ )
Maximum case temperature: 90℃
Storage temperature: -40 ~ 85℃ (Typ. 25℃ )
Working humidity: 20％ RH ~ 90％ RH
Storage humidity: 10％ RH ~ 90％ RH
Warranty: 2 years
Application of Driver LED 5W
Build in lambs such as garden lights, lawn lights, flood lights, three-proof lights, etc.
Model list
| Model | Rated Power | Input Voltage | Output Voltage | Outpot Current | Product Size | Surge |
| GSE-5W300-18 | 5W | 100-265V | 9-18V | 300mA±5% | 66*30*20mm | 1KV |
| GSE-5W250-20 | 100-265V | 9-20V | 250mA±5% | 66*30*20mm | 1KV |
