LBS 40W LED driver
LBS-40W-150A, LBS-40W-150P, LBS-40W-150L
A-Adjustable potentiometer version
P-Off-line programming dimming version
L-Light controlled version
P-Off-line programming dimming version
L-Light controlled version
Quantity:
Parameters:
Input voltage: 120-277V
Output voltage: 80-150V
Rated power: 40W
THD<10%/PF>0.95
Features:
Protections: Input UVP(Power off when voltage<90V), output SCP/OVP/OTP
Certificate: CE/CB/ENEC
Surge: 4/6kV
Efficiency: 92% (Typ.)
IP grade: IP42
Functions: Adjustable potentiometer, off-line programming dimming and light controlled
Warranty: 5 years
Remark: For build-in use only, lamp housing need to be waterproof.
Applications:
Middle and high-end shoebox light,wall light,flood light flat mining light, three anti light, plant light.
Model list:
| Model | Rated power | Input voltage | Output voltage | Comstant power voltage | Output current | Product size | THD | PF |
| LBS-40W-150A | 40W | 120-277V | 80-150V | 100-150V | 150-300mA | 105*53*31mm | <10% | >0.95 |
| LBS-40W-150P | 120-277V | 80-150V | 100-150V | 150-300mA | 105*53*31mm | <10% | >0.95 | |
| LBS-40W-150L | 120-277V | 80-150V | 100-150V | 150-300mA | 105*53*31mm | <10% | >0.95 |
